Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam

  • Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam
  • Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam
Place of Origin China
Brand Name Jovi
Certification CE
Model Number 1-CF-12
Minimum Order Quantity 100m
Price USD 3.19-19.5 per M
Packaging Details Carton or wooden case
Delivery Time 10-15 working days
Payment Terms L/C, T/T
Supply Ability 28000 pcs per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Conductive Fabric, Foam Application RF Cage/room
Length Standard Or Customized Color Gold Silver
Package Carton Or Wooden Case Type All Kinds Of Shape And Size Can Be Customized
Highlight

customized emi shielding gasket

,

12mm x 12mm emi shielding gasket
Leave a Message
Product Description

EMI Shielding Gasket 12mm x 12mm Conductive FoamConductive Foam



Product Information:



Specification

Product Name: Conductive Foams

Product Performance:

Surface Resistive:≤0.05Ω/inch (100gload)

EMI Effectiveness:60dB-80dB/30MHz-1GHz (ASTM4935)

Heat Resistance Temperature: -10℃-110℃

Adhesion Strength:≥ 1.3 (kg/25mm)

Initial Adhesion:1600g/25mm (Non-conductive type)

Keep Adhesion:1440min/inch

Product Composition:

Density:50kg/m3

Elongation:75%

Fire Rating Grade: UL94 (HF-1)



Structure Chart:

Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam 0Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam 1Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam 2Customized Emi Shielding Gasket 12mm X 12mm Conductive Foam 3







FAQ:



Q. Can I have a sample order for conductive foam?

A: Yes, of course, we welcome sample orders to test and check quality.



Q. What about the lead time?

A: Usually 5-7 work days.





Q. How to proceed an order for lead glass?

A: Firstly let us know your requirements or size, shape and also quantity.

Secondly, We quote according to your requirements or our suggestions.

Thirdly customer confirms.

Fourthly We arrange the production.
