1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding

  • 1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding
  • 1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding
Place of Origin China
Brand Name Jovi
Certification CE
Model Number 1-CF-15
Minimum Order Quantity 1 PC
Price USD200-2167/PC
Packaging Details Wrapped in kraft paper, then packed in wooden case. Size according to lead glass size, usually 5 pcs per case.
Delivery Time 5-8 work days
Payment Terms L/C, T/T
Supply Ability 3000PCS per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Lead Glass Application X-ray, CT
Size 15 Mm*1200 Mm*1000 Mm Composition Rmon-pbo-sio2 (B2O3)
Function Xray CT Protection Shape Customized
Frame With Frame Or Without Frame Destiny 4.1g/cm³,4.3g/cm³,4.7g/cm³,5.2g/cm³
Lead Equivalent 1.7mmPb-8mmPb Package Customized Wooden Cases
Highlight

1200 mm*1000 mm radiation protection lead glass

,

radiography department radiation protection lead glass

,

1200mm*1000 mm x ray lead glass
Leave a Message
Product Description

Factory Price 2mmpb 2.5mmpb 3mmpb 4mmpb X ray Lead Glass

Products Description
Depending on your requirements, x-ray protective lead glass can be provided at any size ,
and the lead material used in the glass can vary depending on the strength of protection needed.
1) Model : ZF2 / ZF3 / ZF6 / ZF7
2) Size of Lead glass
X-ray Lead Glass Dimension
L x W
8mm
10mm
12mm
15mm
18mm
20mm
25mm
200 x 300
√
√
√
√
√
√
√
300 x 400
√
√
√
√
√
√
√
400 x 600
√
√
√
√
√
√
√
600 x 800
√
√
√
√
√
√
√
600 x 900
√
√
√
√
√
√
√
1000x800
√
√
√
√
√
√
√
1200x800
√
√
√
√
√
√
√
1200x900
√
√
√
√
√
√
√
1200x1000
√
√
√
√
√
√
√
1200x1200
√
√
√
√
√
√
√
1500x900
√
√
√
√
√
√
√
1500x1000
√
√
√
√
√
√
√
1500x1200
√
√
√
√
√
√
√
1600x1000
√
√
√
√
√
√
√
1600x1200
√
√
√
√
√
√
√
1800x1000
√
√
√
√
√
√
√
1800x1200
√
√
√
√
√
√
√
2000x1000
√
√
√
√
√
√
√
2000x1200
√
√
√
√
√
√
√
2400x1200
×
√
√
√
√
√
√
* Above is standard size , non-standard size can be customized
Above size is always available in our stock , if need other sizes , please contact us freely , we can
produce as per your requirement .
Thickness : 7mm / 8mm / 9mm / 10mm / 12mm / 13mm / 14mm /15mm / 16mm / 17mm / 18mm / 20mm /22mm / 23mm / 24mm / 25mm / 30mm / 40mm
/ 45mm / 50mm / 60mm / 70mm / 80mm / 90mm / 100mm / 110mm / 120mm / 130mm / 140mm / 150mm / 160mm / 180mm / 200mm
2. Terms of medical X ray protective lead glass:
Payment: TT
Delivery time: Abt 3 days after your payment
Packing: Foams and wooden case
Shipping: Tianjin Xingang port.
Specification:
Model
Refractive index
Density (G/cm3)
Lead Equivalent
Sio2 (%)
Pb3O4 (%)
Others (%)
Transparency
ZF2
1.6725
4.2
0.21
39.1
55.41
5.49
90%
ZF3
1.7172
4.46
0.24
33.88
61.05
5.07
85%
ZF6
1.755
4.76
0.27
30.96
65.06
3.98
75%
ZF7
1.06
5.2
0.33
27.27
70.93
1.8
70%



X-ray lead glass is made of high quality optical grade material. It provides excellent radiation shielding, superb visual clarity, high light transmission and does not discolour due to radiation. The hard, polished surfaces have excellent scratch resistance
X-ray Protective glass Anti- radiation Lead glass viewing windows are an important feature for any scanning room ,safely allowing the operator to view their patient in a protective environment.
1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding 0
1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding 1
1200 Mm*1000 Mm Radiation Protection Lead Glass Ct Xray Room Shielding 2
Application of lead shielding glass :
Δ X-ray shielding in hospitals
Δ X-ray rooms MRI scanning
Δ observations windows
Δ door glazing
Δ nuclear medicine application
Δ special mitre joint and lamination with float glass allow extended window sizes, creating better observation environments
Δ multiple glazing units providing shaped observation solutions
Disinfection of Radiation Shielding Glass
Δ only use water, a mild detergent and a soft cloth
Δ Lead glass can be disinfected using commercially available disinfectants that has approved. Disinfection using ultraviolet irradiation is also possible
Δ radiation shielding glass should never be exposed to moisture or temperature fluctuations in conjunction with moisture and acidic air
Δ only use a sealant that is free of acids and alkaline substances (e. g. acetic acid, ammonia) during installation. Adhesive
labels can cause discoloration if the adhesive reacts with the glass surface.
