Ct Room Radiation Protection Lead Glass Size 800mm*1200mm Transparent

  • Ct Room Radiation Protection Lead Glass Size 800mm*1200mm Transparent
  • Ct Room Radiation Protection Lead Glass Size 800mm*1200mm Transparent
Place of Origin China
Brand Name Jovi
Certification CE
Model Number 1-CF-15
Minimum Order Quantity 1 piece
Price USD 600-1200 piece
Packaging Details Wrapped in kraft paper, then packed in wooden case.
Delivery Time 7-14days
Payment Terms T/T, L/C, D/A
Supply Ability 2000 pieces per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Ct Room Lead Glass Size 800mm*1200mm Transparent For Shielding Installation Size Customized/ 800mm X 1200mm
Thickness 15mm Size Lead Equivalent 2.6 Mmpb
Color Transparent Key Word High Shielded Frecuency
Highlight

ct room radiation protection lead glass

,

800mm*1200mm radiation protection lead glass

,

12mm radiation protection glass
Leave a Message
Product Description

Ct Room Lead Glass Size 800mm*1200mm Transparent for Shielding Installation



We use the purest lead available in all our radiation shielding products, ensuring the best use of your budget and space

while providing the most effective lead shielding possible. Our optical-grade lead glass contains 38% lead and 15% barium, resulting in a light amber colored glass suitable for installation in screens, walls, and doors.



Quick Detail:



·Size can be with customized

·Thickness 15mm

·with frame available

·CE Certificate



Application



The properties of lead glass make it useful for many applications. The majority of them, however, make use of its optical properties, in particular. Here are a few examples:



Lead glass almost used in the manufacturing of optical instruments, art vessels, etc.

And known as medical X- ray radiation-proof lead glass plate in the medical field.



Lead glass is thus more fluid and easier to work with and fabricate than soda glass because it can be worked on at

a wider temperature range while still being more malleable and less brittle than ordinary glass.





Attention:



1. When installation, the glass must be mismatched with the wall protection material to prevent radiation leakage at the joint.

2. As lead glass materials are rich in lead and barium, lead glass is easy to be contaminated by acid and base,

and is not easy to be installed or stored in a sour or humid environment.

3. The surface of lead glass is more easily scratched than that of ordinary glass and should be handled with care.





Specification



 8mm

10mm

12mm

15mm

18mm

20mm

25mm


( 1.7mmpb)

( 2.1mmpb)

( 2.6mmpb)

( 3.3 mmpb)

( 3.96 mmpb)

( 4.4 mmpb)

( 6.71 mmpb)

200* 300

200* 300* 8

200* 300* 10

200* 300* 12

200* 300* 15

200* 300* 18

200* 300* 20

-

300* 400

300* 400* 8

300* 400* 10

300* 400* 12

300* 400* 15

300* 400* 18

300* 400* 20

-

400* 600

400* 600* 8

400* 600* 10

400* 600* 12

400* 600* 15

400* 600* 18

400* 600* 20

-

600* 800

600* 800* 8

600* 800* 10

600* 800* 12

600* 800* 15

600* 800* 18

600* 800* 20

-

600* 900

600* 900* 8

600* 900* 10

600* 900* 12

600* 900* 15

600* 900* 18

600* 900* 20

-

1000* 800

1000* 800* 8

1000* 800* 10

1000* 800* 12

1000* 800* 15

1000* 800* 18

1000* 800* 20

1000* 800* 25

1200* 800

1200* 800* 8

1200* 800* 10

1200* 800* 12

1200* 800* 15

1200* 800* 18

1200* 800* 20

1200* 800* 25

1200* 900

1200* 900* 8

1200* 900* 10

1200* 900* 12

1200* 900* 15

1200* 900* 18

1200* 900* 20

1200* 900* 25

1200* 1000

1200* 1000* 8

1200* 1000* 10

1200* 1000* 12

1200* 1000* 15

1200* 1000* 18

1200* 1000* 20

1200* 1000* 25

1200* 1200

-

1200* 1200* 10

1200* 1200* 12

1200* 1200* 15

1200* 1200* 18

1200* 1200* 20

1200* 1200* 25

1500* 900

-

1500* 900* 10

1500* 900* 12

1500* 900* 15

1500* 900* 18

1500* 900* 20

1500* 900* 25

1500* 1000

-

1500* 1000* 10

1500* 1000* 12

1500* 1000* 15

1500* 1000* 18

1500* 1000* 20

1500* 1000* 25

1500* 1200

-

1500* 1200* 10

1500* 1200* 12

1500* 1200* 15

1500* 1200* 18

1500* 1200* 20

1500* 1200* 25

1600* 1000

-

1600* 1000* 10

1600* 1000* 12

1600* 1000* 15

1600* 1000* 18

1600* 1000* 20

1600* 1000* 25

1600* 1200

-

1600* 1200* 10

1600* 1200* 12

1600* 1200* 15

1600* 1200* 18

1600* 1200* 20

1600* 1200* 25

1800* 1000

-

1800* 1000* 10

1800* 1000* 12

1800* 1000* 15

1800* 1000* 18

1800* 1000* 20

1800* 1000* 25

1800* 1200

-

1800* 1200* 10

1800* 1200* 12

1800* 1200* 15

1800* 1200* 18

1800* 1200* 20

1800* 1200* 25

2000* 1000

-

2000* 1000* 10

2000* 1000* 12

2000* 1000* 15

2000* 1000* 18

2000* 1000* 20

2000* 1000* 25

2000* 1200

-

2000* 1200* 10

2000* 1200* 12

2000* 1200* 15

2000* 1200* 18

2000* 1200* 20

2000* 1200* 25

2400* 1200

-

2400* 1200* 10

2400* 1200* 12

2400* 1200* 15

2400* 1200* 18

2400* 1200* 20

2400* 1200* 25







We will also customize the size according to customer requirements, the largest size we have customized is as follows

1500mm size x 3000mm size for their CT Rooom installation.

Ct Room Radiation Protection Lead Glass Size 800mm*1200mm Transparent 0







After-Service:



1. Delivery within 10 days after receiving payments.

2. Offer Different Shipping Ways to our customers.

3. Track the order until you get the products

4. In usual, sea port we used is in Tianjin, Shenzhen...
